Product Features

- Multi-zone technology: Multiple overlapping detection areas

- Superior casing protection: Uses high-density fire-resistant materials

- Password protection: Only authorized operators can use the system

- High sensitivity: 360° no-blind-spot detection of a 5-cent coin RMB in the central area

- Self-adaptive diagnostic system: Automatically diagnoses when powered on, no initial or periodic calibration needed

- Anti-interference: 99 adjustable working frequencies, multiple devices can operate simultaneously with light alarms

- Safety: Harmless to pacemaker wearers, pregnant women, and magnetic media

- Modular design: Easy to maintain and replace

- Detection capability: Can process more than 60-150 people per minute

- Turnstile integration: Support coordinates with turnstiles to manage individuals who trigger alarms

- Magnetic field separation principle: 33 individual grid-like magnetic fields for independent detection and real-time calculations

Technical Parameters

- 33 independent detection zones

- Overall sensitivity: 0-300 levels

- Frequency: 99 options

- Power consumption: <35W

- Throughput rate: 0.4m/s to 1.2m/s

- Internal passage dimensions: 1960x720mm

-Overall external dimensions: 2340(H)x920(W)x750(D)mm

- Operating voltage: AC110V/240V, 50/60Hz

- Operating temperature: -20℃ to +45℃

- Net weight: 125KG - Gross weight: 150KG

Reminder:

If you have any questions regarding our walk-through metal detector products,

please contact our Cindy WhatsAPP +86 19128381863 online support or send an email(cindy@mcddetection.com).

We are happy to provide professional advice to meet your needs.

All data are based on Chinese standard test pieces (STP).
