Technical parameters

1, Accurate positioning: six overlapping mesh metal detection area on each side, with a large LCD screen human body background map, intuitive and accurate positioning of the location of the person to be tested to carry metal.

2、Detection sensitivity, in line with the first, second, third and mixed categories;

3, super anti-interference performance: security gate around the presence of large pieces of metal within 5cm, the device is still able to detect normal;

4, The detection results of wireless real-time cell phone push function: through the WeChat small program real-time view of the current detection information, including metal alarm information, temperature detection data;

5, cell phone wireless remote control function: through the cell phone program to set the parameters of the device, including setting the metal detection sensitivity;

6, sleep function: the user can set the sleep time, when the device reaches the sleep time, it will automatically enter the low-power mode.

7, Metal volume indication function: 10.1-inch LCD screen can indicate the current amount of detected metal through the energy column;

8, Self-learning function: when selecting a particular target metal as a learning object for recording, the subsequent amount of metal is greater than the test object, the device alarm, otherwise, the device, the device does not alarm.

9, The minimum detection height: 2cm from the ground with a diameter of 20mm iron ball as a test object, at a speed of 1 meter per second through the security gate, the equipment alarm.

10, Weak magnetic field emission technology: in line with all the current international safety standards adopted, the use of weak magnetic field technology, the cardiac pacemaker wearer, pregnant women, floppy disks, film, video tapes, etc. without damage.

11, Can be human body temperature detection, voice broadcast.

12,Operating voltage: AC220V 50/60Hz

13, Power: ≤ 35W

14, Signal frequency: 6-9KHz (adjustable)

15, Operating temperature: -10 ℃ -55 ℃

16、Storage temperature：-25℃--75℃

17、Packaging weight of the whole machine: about 60KG

18,Transportation weight: about 85KG (wooden case)

19,Outside dimensions: 2220mm (H) × 800mm (W) × 660mm (D)

20, Channel size: 2000mm (H) × 700mm (W) × 550mm (D)

21,Light bar display: the device can display the corresponding zone alarm through the light bar.

22,Sensitivity level: 4000 level.

23, Flying object alarm: can block the infrared after the dollar coin flying object alarm.

24, Single-zone, multi-zone switching: support for single-zone position, multi-zone mode switching function. Maximum 18 zones.

25,Anti-static metal objects: 1), anti-static metal objects around the impact: the detection performance of the equipment should not be affected by the door around the 1m range outside the large static metal objects; 2), anti-ground internal metal structure: the performance of the equipment should not be affected by the ground 0.1m below the impact of metal structures.

26, Detection mode switching: equipment with non-ferrous metal detection mode and ferrous metal detection mode.

27,  Cell phone detection mode: the device can be set to detect cell phone mode, sensitivity settings for 0-4000, excluding keys, belt buckles, coins, watches, small metal objects, with a cell phone through the door corresponding to the area of the alarm.
